Media station | Connection | Product code |
SXR Capture Drive Dock | Thunderbolt 3 | CDX-75013-1 |
SXR Capture Drive Dock | Thunderbolt 2 | CDX-75013 and CDX-75014 |
Transfer Drive Dock | Dual Thunderbolt 3 | CX.0001063 |
Capture +Transfer Drive (Classic) Dock | Thunderbolt 3 | CDX-62103-3 |
Transfer Drive (Classic) Dock | Thunderbolt 3 | CDX-62103-2 |
XR Capture Drive Dock | Thunderbolt 1 | CDX-7513 |
XR Capture Drive Dock | USB-3 | CDX-7510, CDX-75102, CDX-75112 |
Dual XR Capture Drive Dock | SAS | CDX-5513, CDX-75002, CDX-7500 |
Desktop Transfer Station | SAS |
Device Manager is a macOS application. There is currently no support for Windows.
This section includes installation guides for Apple Silicon and Intel based Macs for either macOS 12 Monterey and below, or macOS 13 Ventura or above.
IMPORTANT: The following intructions relate to installing Device Manager 6.2.0.
System requirements:
Download Device Manager Software
Device Manager software can be downloaded from the CODEX Software Downloads page.
Installation
The steps below must be completed in order for the CODEX Platform and Device Manager software to function correctly.
Open the downloaded .pkg file. Follow the installer prompts to proceed with software installation.
Any items that are not already installed will be selected by default, with the exception of the ATTO SAS driver. If using a Transfer Drive Dock (Classic), the ATTO SAS driver is required. Original models of the Transfer Drive Dock (Classic) require the H608 driver, and the latest Transfer Drive Dock (Classic) require the H1208GT driver. If you are unsure which driver is needed for your Transfer Drive Dock (Classic), then please install both ATTO drivers. The Dual XR Capture Drive Dock (SAS) also requires the ATTO SAS driver H608.
For new installations you will be prompted to Open Security Preferences to allow the software to run:
Click Open Security Preferences to access System Preferences > Security & Privacy > General.
*If you have not installed Device Manager (or other software using System Extensions) previously, then you will need to enable System Extensions on your Mac. See the Enabling System Extensions section below. If you have already enabled system extensions, then please skip to the Allowing System Extensions in System Preferences section.
Enabling System Extensions
CODEX Device Manager uses System Extensions to integrate with macOS for low level access to hardware devices, such as CODEX Compact Drive Docks.
Click the Enable system extensions... button in System Preferences > Security & Privacy > General.
This will give you instructions on how to launch the Startup Security Utility and modify your security settings to enable System Extensions.
1. Shutdown your Mac, and then press and hold the Touch ID or power button until you enter macOS Recovery.
2. Select Options and then Continue.
3. Select your Mac’s administrator account and enter the password.
4. Click Utilities in the menu bar and select Startup Security Utility.
5. Select your startup disk and click the Security Policy button. (If the disk is encrypted with FileVault, click Unlock, enter the password, then click Unlock.)
6. Select the radio button next to Reduced Security. Then, check the box next to Allow user management of kernel extensions from identified developers.
This option will allow you to choose which developer's System Extensions you would like to allow within macOS System Settings.
7. Click OK and Restart
Allowing System Extensions in System Preferences
Once your Mac has restarted, you will see a CODEX Driver Error popup.
To resolve this:
1. Go to System Preferences > Security & Privacy > General. In the lower section, you will see a warning, such as Some system software requires your attention before it can be used.
2. Click Details... to open a window allowing you to choose the System Extensions from the developers you would like to allow. CODEX Device Manager uses system extensions from the following developers:
- X2X Limited (CODEX software)
- ATTO Technology, Inc (For use with Transfer Drive Classic and Dual XR Capture Drive Dock)
- JMicron Technology Corp (Firmware update utility for the Compact Drive Reader - USB-C)
3. Check the above developers and click OK.
Enabling Full Disk Access
CODEX Device Manager also requires Full Disk Access to be enabled in order to manage your CODEX media and media stations. During installation, you may see a popup warning asking you to open System Preferences to allow Full Disk Access for drserver.
To enable Full Disk Access, open System Preferences > Security and Privacy > Privacy and scroll down to the Full Disk Access section. Enable the button next to the drserver item.
If you were not prompted to Restart at the end of the installation, then we recommend you Restart manually.
The Device Manager menu bar app will now be accessible from the top-right of your screen after installation.
IMPORTANT: The following intructions relate to installing Device Manager 6.2.0.
System requirements:
Download Device Manager Software
Device Manager software can be downloaded from the CODEX Software Downloads page.
Installation
The steps below must be completed in order for the CODEX Platform and Device Manager software to function correctly.
Open the downloaded .pkg file. Follow the installer prompts to proceed with software installation.
Any items that are not already installed will be selected by default, with the exception of the ATTO SAS driver. If using a Transfer Drive Dock (Classic), the ATTO SAS driver is required. Original models of the Transfer Drive Dock (Classic) require the H608 driver, and the latest Transfer Drive Dock (Classic) require the H1208GT driver. If you are unsure which driver is needed for your Transfer Drive Dock (Classic), then please install both ATTO drivers. The Dual XR Capture Drive Dock (SAS) also requires the ATTO SAS driver H608.
For new installations you will be prompted to open System Settings > Privacy & Security to allow the software to run:
Click Open System Settings to access System Settings > Privacy & Security and scroll down the page to the Security section.
*If you have not installed Device Manager (or other software using System Extensions) previously, then you will need to Enable System Extensions. See the Enabling System Extensions section below. If you have already enabled system extensions, then please skip to the Allowing System Extensions in System Settings section.
Enabling System Extensions
CODEX Device Manager uses System Extensions to integrate with macOS for low level access to hardware devices, such as CODEX Compact Drive Docks.
Click the Enable System Extensions button in the Security section of the System Settings > Privacy & Security panel.
This will give you instructions on how to launch the Startup Security Utility and modify your security settings to enable System Extensions.
1. Shutdown your Mac, and then press and hold the Touch ID or power button until you enter macOS Recovery.
2. Select Options and then Continue.
3. Select your Mac’s administrator account and enter the password.
4. Click Utilities in the menu bar and select Startup Security Utility.
5. Select your startup disk and click the Security Policy button. (If the disk is encrypted with FileVault, click Unlock, enter the password, then click Unlock.)
6. Select the radio button next to Reduced Security. Then, check the box next to Allow user management of kernel extensions from identified developers.
This option will allow you to choose which developer's System Extensions you would like to allow within macOS System Settings.
7. Click OK and Restart
Allowing System Extensions in System Settings
Once your Mac has restarted, you will see a CODEX Driver Error popup. To resolve this:
1. Go to System Settings > Privacy & Security and scroll down to the Security section.
2. Click Details... next to where you see the warning Some system software requires your attention before it can be used to open a window allowing you to choose the System Extensions from the developers you would like to allow. CODEX Device Manager uses system extensions from the following developers:
- X2X Limited (CODEX software)
- ATTO Technology, Inc (For use with Transfer Drive Classic and Dual XR Capture Drive Dock)
- JMicron Technology Corp (Firmware update utility for the Compact Drive Reader - USB-C)
3. Check the above developers and click OK.
Enabling Full Disk Access
CODEX Device Manager also requires Full Disk Access to be enabled in order to manage your CODEX media and media stations. During installation, you may see a popup warning asking you to open System Settings to allow Full Disk Access for drserver.
To enable Full Disk Access, open System Settings > Privacy & Security and scroll down to the Full Disk Access section. Enable the button next to the drserver item.
If you were not prompted to Restart at the end of the installation, then we recommend that you Restart manually.
The Device Manager menu bar app will now be accessible from the top-right of your screen after installation.
IMPORTANT: The following intructions relate to installing Device Manager 6.2.0.
System requirements:
Download Device Manager Software
Device Manager software can be downloaded from the CODEX Software Downloads page.
Installation
The steps below must be completed in order for the CODEX Platform and Device Manager software to function correctly.
Open the downloaded .pkg file. Follow the installer prompts to proceed with the software installation.
Any items that are not already installed will be selected by default, with the exception of the ATTO SAS driver. If using a Transfer Drive Dock (Classic), the ATTO SAS driver is required. Original models of the Transfer Drive Dock (Classic) require the H608 driver, and the latest Transfer Drive Dock (Classic) require the H1208GT driver. If you are unsure which driver is needed for your Transfer Drive Dock (Classic), then please install both ATTO drivers. The Dual XR Capture Drive Dock (SAS) also requires the ATTO SAS driver H608.
For new installations you will be prompted to open Open Security Preferences to allow the software to run:
Click Open Security Preferences to access System Preferences > Security & Privacy > General.
*NOTE: Until you have modified your security settings, you may also see the following popup warning:
To resolve this:
1. Go to System Preferences > Security & Privacy > General. In the lower section, you will see a warning, such as Some system software requires your attention before it can be used.
2. Click Details... to open a window allowing you to choose the System Extensions from the developers you would like to allow. CODEX Device Manager uses system extensions from the following developers:
- X2X Limited (CODEX software)
- ATTO Technology, Inc (For use with Transfer Drive Classic and Dual XR Capture Drive Dock)
- JMicron Technology Corp (Firmware update utility for the Compact Drive Reader - USB-C)
3. Check the above developers and click OK.
Enabling Full Disk Access
CODEX Device Manager also requires Full Disk Access to be enabled in order to manage your CODEX media and media stations. During installation, you may see a popup warning asking you to open System Preferences to allow Full Disk Access for drserver.
To enable Full Disk Access, open System Preferences > Security and Privacy > Privacy and scroll down to the Full Disk Access section. Enable the button next to the drserver item.
If you were not prompted to Restart at the end of the installation, then we recommend that you Restart manually.
The Device Manager menu bar app will now be accessible from the top-right of your screen after installation.
IMPORTANT: The following intructions relate to installing Device Manager 6.2.0.
System requirements
Download Device Manager Software
Device Manager software can be downloaded from the CODEX Software Downloads page.
Installation
The steps below must be completed in order for the CODEX Platform and Device Manager software to function correctly.
Open the downloaded .pkg file. Follow the installer prompts to proceed with the software installation.
Any items that are not already installed will be selected by default, with the exception of the ATTO SAS driver. If using a Transfer Drive Dock (Classic), the ATTO SAS driver is required. Original models of the Transfer Drive Dock (Classic) require the H608 driver, and the latest Transfer Drive Dock (Classic) require the H1208GT driver. If you are unsure which driver is needed for your Transfer Drive Dock (Classic), then please install both ATTO drivers. The Dual XR Capture Drive Dock (SAS) also requires the ATTO SAS driver H608.
3. For new installations you will be prompted to open System Settings > Privacy & Security to allow the software to run:
Click Open System Settings to access System Settings > Privacy & Security and scroll down the page to the Security section.
NOTE: You may see a CODEX Driver Error popup warning until you have enabled the System Extensions detailed below.
1. Go to System Settings > Privacy & Security and scroll down to the Security section. You will see the warning that Some system software requires your attention before it can be used.
2. Click Details... to open a window allowing you to choose the System Extensions from the developers you would like to allow. CODEX Device Manager uses system extensions from the following developers:
- X2X Limited (CODEX software)
- ATTO Technology, Inc (For use with Transfer Drive Classic and Dual XR Capture Drive Dock)
- JMicron Technology Corp (Firmware update utility for the Compact Drive Reader - USB-C)
3. Check the above developers and click OK.
Enabling Full Disk Access
CODEX Device Manager also requires Full Disk Access to be enabled in order to manage your CODEX media and media stations. During installation, you may see a popup warning asking you to open System Settings to allow Full Disk Access for drserver.
To enable Full Disk Access, open System Settings > Privacy & Security and scroll down to the Full Disk Access section. Enable the button next to the drserver item.
If you were not prompted to Restart at the end of the installation, then we recommend that you Restart manually.
The Device Manager menu bar app will now be accessible from the top-right of your screen after installation.
The Preferences > HDE panel is where HDE mode can be enabled for clips recorded in ARRIRAW on Capture Drive or Compact Drive:
When the checkbox is active, ARRIRAW on Capture Drives and Compact Drives is available as HDE files*.
*HDE ARRIRAW from ALEXA 35 is presented as .mxf files. HDE ARRIRAW from earlier camera models is presented as .arx files.
Compact Drives (ALEXA 35):
Compact Drives recorded on the ALEXA 35 are formatted as UDF whether recording in ARRIRAW or ProRes mode.
For source volumes that are formatted as UDF from the ARRI ALEXA 35, the original volume contains the source .mxf files. Device Manager presents an additional volume with a "_hde" suffix that contains the HDE files when the HDE checkbox is enabled.
When the checkbox is enabled HDE files* will be presented in an additional volume on your Desktop with “_hde” appended to the volume name (for example: A001R01D_hde). The original ARRIRAW .mxf files will also be available in the standard volume on your Desktop (for example: A001R01D).
When the checkbox is disabled the original ARRIRAW .mxf files will be available in the standard volume on your Desktop (for example: A001R01D).
For ALEXA 35, the HDE volume will contain HDE files in the form of a an HDE .mxf file.*
For ALEXA 35 .mxf files, the filename contains a codec identifier (a=ARRIRAW, p=ProRes, h=HDE), based on the file naming specification from ARRI. For HDE .mxf files, the name contains an "h" identifier. See the table below for examples of the codex identifier in these filenames:
MXF File Format | Identifier | Example Filename |
ARRIRAW | a | A_0001C001_230624_165927_a1DB2.mxf |
HDE ARRIRAW | h | A_0001C001_230624_165927_h1DB2.mxf |
Apple ProRes | p | A_0001C001_230624_165927_p1DB2.mxf |
Example: Here you can see a Compact Drive recorded on the ALEXA 35 has been loaded. The HDE ARRIRAW checkbox is enabled and so there are 2 x volumes mounted on the Desktop. A_0026_1BXC contains the original ARRIRAW .mxf files and A_0026_1BXC_hde contains the HDE ARRIRAW .mxf files. The codec identifer h
is included in the filename to indicate the mxf files are in HDE ARRIRAW format.
Compact Drives (ALEXA Mini LF):
Compact Drives recorded on the ALEXA Mini LF are formatted as UDF whether recording in ARRIRAW or ProRes mode.
For source volumes that are formatted as UDF from the ARRI ALEXA Mini LF and ALEXA Mini, the original volume contains the source .mxf files. Device Manager presents an additional volume with a "_hde" suffix that contains the HDE files when the HDE checkbox is enabled.
When the checkbox is enabled HDE files* will be presented in an additional volume on your Desktop with “_hde” appended to the volume name (for example: A001R01D_hde). The original ARRIRAW .mxf files will also be available in the standard volume on your Desktop (for example: A001R01D).
When the checkbox is disabled the original ARRIRAW .mxf files will be available in the standard volume on your Desktop (for example: A001R01D).
For ALEXA Mini LF, the HDE volume will contain HDE files in the form of a folder per clip containing a sequence of .arx files (1 file per frame).*
Example: Here you can see a Compact Drive recorded on the ALEXA Mini LF has been loaded. The HDE ARRIRAW checkbox is enabled and so there are 2 x volumes mounted on the Desktop. A047ROIR contains the original ARRIRAW .mxf files and A047ROIR_hde contains the HDE ARRIRAW .arx files.
Capture Drives (ALEXA LF, SXT and XT):
Capture Drives recorded on the ALEXA LF, SXT or XT are formatted as CodexFS when recording in ARRIRAW mode, or UDF when recording in ProRes mode.
For source volumes that are formatted as CodexFS on older ARRI cameras such as ALEXA LF, SXT, and XT, then Device Manager presents a volume with no "_hde" suffix where files are either .ari or .arx. The contents of this folder (.ari or .arx) will change dynamically depending on whether the HDE ARRIRAW checkbox is enabled or disabled.
Example: Here you can see a Capture Drive recorded on the ALEXA SXT has been loaded. It has a single volume (A144R5NN) mounted on the Desktop. The HDE ARRIRAW checkbox is enabled, so the volume contains .arx files.
CFast 2.0 Cards (ALEXA Mini):
CFast 2.0 cards recorded on the ALEXA Mini are formatted as UDF. The original volume contains the source .mxf files. Device Manager presents an additional volume with a "_hde" suffix that contains the HDE files when the HDE checkbox is enabled.
*HDE ARRIRAW from ALEXA 35 is presented as .mxf files. HDE ARRIRAW from earlier camera models is presented as .arx files
Go to the High Density Encoding page for more information.
IP | The network IP address of the detected MediaVault on your network. The system may have other IP addresses on other ports, but this is the address by which a connection will be made. |
Model | The model number of the MediaVault system - D1200 / R1200 / R3600. |
Serial Number | The serial number of the MediaVault system. |
To uninstall Device Manager go to System Preferences (or System Settings) > CODEX, click the lock symbol and enter your macOS user password when prompted.
Then follow these steps:
Periodically CODEX will issue firmware updates for CODEX Media Stations. These firmware updates will be included in Device Manager software*.
How to check if a firmware update is available for your CODEX Media Station
IMPORTANT: The information below applies to all CODEX Media Stations, with the exception of the Compact Drive Reader USB-C (CX.0001005). For information on updating the firmware for the Compact Drive Reader USB-C, please see the Updating Firmware for the Compact Drive Reader section.
How to update firmware on your CODEX Media Station
IMPORTANT: Please ensure you only have 1 x CODEX Media Station connected at each time when updating firmware! These instructions DO NOT apply to the Compact Drive Reader (see above).
To update the firmware on your CODEX Media Stations, please ensure only 1 x CODEX Media Station is connected, and then follow the steps above to check if a firmware update is available for that device.
1. If an update is available, then click the Update Firmware... option in the Device Manager menu. This will open the CODEX System Preferences panel.
2. Unlock the System Preferences panel by clicking the lock symbol in the bottom-left, and then click Stop Server. Please wait for the System Preferences panel to report Server is stopped in the top-left - this may take up to 2 minutes.
3. Click on the Hardware tab and click Refresh. You should now see your Media Station listed in the Firmware info: section.
4. If your Media Station is listed and a firmware update is available, you can now click Auto Upgrade... to start the firmware update procedure. This may take up to 30 seconds to complete.
IMPORTANT: Do not disconnect your Media Station or eject the Media during the firmware update process. Doing so may cause damage to the device.
5. Once the update is complete, you may click the Refresh button, which will now display the new firmware version of the device.
Problems Updating Firmware on your Media Station?
If you have any questions, or problems during the firmware update process, please contact the CODEX Support team.
*Please note: Firmware updates are currently macOS only.
Description (Model) | Connection | Bus speed * | PCIE over TB speed |
Compact Drive Dock (CX.0001007) | TB 3 | 40 Gbps | Approx. 22 Gbps |
SXR Capture Drive Dock (CDX-75013-1) | TB 3 | 40 Gbps | Approx. 22 Gbps |
Capture + Transfer Drive Dock (CDX-62102-3) | TB 3 | 40 Gbps | Approx. 22 Gbps |
SXR Capture Drive Dock (CDX-75013 / CDX-75014) | TB 2 | 20 Gbps | Approx. 11 Gbps |
XR Capture Drive Dock (CDX-7513) | TB 1 | 10 Gbps | Approx. 6 Gbps |
*Note that PCIe over Thunderbolt, as used by CODEX Media Stations, cannot achieve the maximum possible bus speed as Thunderbolt reserves some bandwidth for other purposes such as display devices. In addition, driver/software layers have overhead that limit speeds to below the maximum bus speed.
The Thunderbolt connection speed is governed by:
**For the best possible speed and reliability we recommended not using Codex Thunderbolt Docks as part of a daisy-chain of devices.
To resolve the situation, the following steps should be taken:
An 'Update Firmware...' message appears. What should I do?
See the Updating Firmware on CODEX Media Stations section for more information.
A 'Reduced Performance` message appears. What should I do?
Rev A Compact Drive Readers will have reduced performance with Apple Silicon. See the Compact Drive Reader > Use with Apple Silicon Macs section for more information.
A ' Requires macOS 12.4 or later' message appears. What should I do?
Rev A Compact Drive Readers have an incompatibility with Apple Silicon on macOS 12.3 or below. See the Compact Drive Reader > Use with Apple Silicon Macs section for more information.
sudo kextunload -v /Library/Extensions/jmPeripheralDevice.kext
Saturday 23rd | 9am - 5pm GMT |
Sunday 24th | 9am - 5pm GMT |
Monday 25th | CLOSED - Merry Christmas! |
Tuesday 26th | 8:30am - 5:30pm PST |
Wednesday 27th | 9am - 5pm GMT | 8:30am - 5:30pm PST |
Thursday 28th | 9am - 5pm GMT | 8:30am - 5:30pm PST |
Friday 29th | 9am - 5pm GMT | 8:30am - 5:30pm PST |
Saturday 30th | 9am - 5pm GMT |
Sunday 31st | 9am - 5pm GMT |
Monday 1st | CLOSED - Happy New Year! |
Tuesday 2nd | Normal hours resume |
